Product Summary

The SIM900B is a complete Quad-Band GSM / GPRS module in a board-to-board type layout, and is designed with a very powerful single-chip processor integrating the ARM926EJ-S core. Further-more, the new module is mechanically compatible with SIM300 / SIM340 and the SIM340E. Com-bining high performance and low power consumption, SIM900B is an ideal wireless module for many M2M applications.

Parametrics

SIM900B characteristics: (1)GPRS class 10: max. 85.6 kbps; (2)Coding schemes: CS 1, 2, 3, 4 ; (3)CSD: up to 14.4 kbps ; (4)Quad-Band: 850/ 900/ 1800/ 1900 MHz ; (5)GPRS multi-slot class 10/8 ; (6)GPRS mobile station class B ; (7)Compliant to GSM phase 2/2+ ; (8)Class 4 (2 W at 850/ 900 MHz) ; (9)Class 1 (1 W at 1800/1900MHz) ; (10)Dimensions: 40* 33* 3 mm ; (11)Weight: 7g ; (12)Supply voltage range 3.4 to 4.5V ; (13)Normal Operation temperature: -30℃ to +80℃.

Features

SIM900B features: (1)Compatible with SIM300 / SIM340 and SIM340E; (2)60 pin board-to-board connector; (3)GSM / GPRS 850 / 900 / 1800 / 1900; (4)Operating Temperature: -40℃ to +85℃; (5)Sleep Mode Power Consumption: 1.5mA; (6)Embedded SIM (Option); (7)Embedded SIM Holder (Option).
