Product Summary

The OPA4344UA is a rail-to-rail CMOS operational amplifier designed for precision, low- power, miniature applications. The OPA4344UA is unity gain stable. The OPA4344UA is optimized to operate on a single supply from 2.5V and up to 5.5V with an input common-mode voltage range that extends 300mV beyond the supplies. Quiescent current is only 250μA (max). The applications of the OPA4344UA include pcmcia cards, data acquisition, process control, audio processing, communications, active filters and test equipment.

Parametrics

OPA4344UA absolute maximum ratings: (1)Supply Voltage, V+ to V-: 7.5V; (2)Signal Input Terminals, Voltage: (V–) –0.5V to (V+) +0.5V; Current: 10mA; (3)Output Short-Circuit: Continuous; (4)Operating Temperature:–55℃ to +125℃; (5)Storage Temperature: –65℃ to +150℃; (6)Junction Temperature: 150℃; (7)Lead Temperature (soldering, 10s): 300℃; (8)ESD Tolerance (Human Body Model): 4000V.

Features

OPA4344UA features: (1)rail-to-rail input; (2)rail-to-rail output (within 1mV); (3)low quiescent current: 150μA typ; (4)microsize packages: SOT23-5, MSOP-8, TSSOP-14; (5)gain-bandwidth: 1MHz, G ≥ 1; (6)slew rate: 0.8V/μs; (7)THD + noise: 0.006%.

Diagrams

OPA4344UA pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
OPA4344UA
OPA4344UA
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply Rail-to-Rail
Data Sheet
0-1: $2.32
1-25: $1.86
25-100: $1.69
100-250: $1.53
OPA4344UA/2K5
OPA4344UA/2K5
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply Rail-to-Rail
Data Sheet
0-1860: $0.92
1860-2000: $0.89
2000-2500: $0.89
2500-5000: $0.85
OPA4344UAG4
OPA4344UAG4
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply Rail-to-Rail
Data Sheet
0-1: $2.03
1-25: $1.70
25-100: $1.49
100-250: $1.30
OPA4344UA/2K5G4
OPA4344UA/2K5G4
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply Rail-to-Rail
Data Sheet
0-1860: $0.92
1860-2000: $0.89
2000-2500: $0.89
2500-5000: $0.85
