Product Summary

The MBRF2045CT is a switchmode power rectifier designed for Power Supply-Output Rectification, Power Management, Instrumentation.

Parametrics

MBRF2045CT maximum ratings: (1)Peak Repetitive Reverse Voltage, VRRM: 45 V; (2)Working Peak Reverse Voltage, VRWM: 45 V; (3)DC Blocking Voltage, VR: 45 V; (4)Average Rectified Forward Current: Per Device, IF(AV)=20A; Per Diode (TC = 165℃); IF(AV)=10A ; (5)Peak Repetitive Forward Current per Diode Leg (Square Wave, 20 kHz, TC = 163℃), IFRM: 20 A; (6)Non Repetitive Peak Surge Current(Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz), IFSM: 150 A; (7)Peak Repetitive Reverse Surge Current (2.0 us, 1.0 kHz), IRRM: 1.0 A; (8)Storage Temperature Range, Tstg: -65 to +175 ℃; (9)Operating Junction Temperature, TJ: -65 to +175 ℃; (10)Voltage Rate of Change (Rated VR), dv/dt: 10,000 V/us.

Features

MBRF2045CT features: (1)Low Forward Voltage; (2)Low Power Loss / High Efficiency; (3)High Surge Capacity; (4)175℃ Operating Junction Temperature; (5)20 A Total (10 A Per Diode Leg); (6)Pb-Free Package is Available.

Diagrams

MBRF2045CT diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MBRF2045CT
MBRF2045CT
Taiwan Semiconductor
Schottky (Diodes & Rectifiers) 20 Amp 45 Volt Dual
Data Sheet
0-2000: $0.42
2000-4000: $0.37
4000-6000: $0.33
MBRF2045CT-E3/45
MBRF2045CT-E3/45
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 45 Volt 20A Dual Common-Cathode
Data Sheet
0-1: $1.11
1-10: $1.00
10-100: $0.84
100-250: $0.75
MBRF2045CTG
MBRF2045CTG
ON Semiconductor
Schottky (Diodes & Rectifiers) 20A 45V RECTIFIER
Data Sheet
0-1: $0.41
1-25: $0.40
25-100: $0.39
100-250: $0.38
MBRF2045CTHE3/45
MBRF2045CTHE3/45
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 45 Volt 20A Dual Common-Cathode
Data Sheet
0-430: $0.75
430-500: $0.66
500-1000: $0.57
1000-2000: $0.49
