LM358DT

dual operational amplifier, 8-SOIC, 1.1MHz, 60mA, 3 V ~ 30 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.13~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.13~0.80

PartNumber:: LM358DT

Brand:: STMicroelectronics - ST | Pack: SO | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Tom's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-23

From Other Seller

Part Number:LM358DT
US $0.13 - 0.80
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM358DT is a Low power dual operational amplifier. The LM358DT consists of two independent, high-gain, internally frequency-compensated op-amps which are designed specifically to operate from a single power supply over a wide range of voltages. Application areas of the LM358DT include transducer amplifiers, DC gain blocks and all the conventional op-amp circuits which now can be more easily implemented in single power supply systems.

Parametrics

LM358DT absolute maximum ratings: (1)Supply voltage:±16V or ±32 V; (2)Input voltage:32 V; (3)Differential input voltage:32 V; (4)Output short-circuit duation:Infinite; (5)Input current:50 mA; (6)Operating free-air temperature range:0℃ to +70℃; (7)Storage temperature range:-65℃ to +150℃; (8)Maximum junction temperature:150℃; (9)Thermal resistance junction to ambient:125℃/W; (10)Thermal resistance junction to case:40℃/W; (11)HBM: human body model:300 V; (12)MM: machine model:200 V; (13)CDM: charged device model:1.5 kV.

Features

LM358DT features: (1)Internally frequency compensated; (2)Large DC voltage gain: 100 dB; (3)Wide bandwidth (unity gain): 1.1 MHz(temperature compensated); (4)Very low supply current per operator essentially independent of supply voltage; (5)Low input bias current: 20 nA(temperature compensated); (6)Low input offset voltage: 2 mV; (7)Low input offset current: 2 nA; (8)Input common-mode voltage range includes negative rails; (9)Differential input voltage range equal to the power supply voltage; (10)Large output voltage swing 0 V to (VCC+ - 1.5V).
