Product Summary
The BUK455-100A is an N-channel enhancement mode field-effect power transistor in a plastic envelope. The device is intended for use in Switched Mode Power Supplies (SMPS), motor control, welding, DC/DC and AC/DC converters, and in general purpose switching applications.
Parametrics
BUK455-100A absolute maximum ratings: (1)VDS, Drain-source voltage: 100 V; (2)VDGR, Drain-gate voltage: 100 V; (3)±VGS, Gate-source voltage: 30 V; (4)ID, Drain current (DC): 26 A; (5)ID, Drain current (DC): 18 A; (6)IDM, Drain current (pulse peak value): 104 A; (7)Ptot, Total power dissipation: 125 W; (8)Tstg, Storage temperature: - 55 to 175℃; (9)TJ, Junction Temperature: - 175℃.
Features
BUK455-100A features: (1)VDS, Drain-source voltage: 100V; (2)ID Drain current (DC): 26 A; (3)Ptot, Total power dissipation: 125W; (4)Tj, Junction temperature: 175℃; (5)RDS(ON), Drain-source on-state resistance: 0.08Ω.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
BUK455-100A |
Other |
Data Sheet |
Negotiable |
|
||||||
