The SN74LVC126APWR is a quadruple bus buffer gate with 3-state outputs. It is designed for 1.65-V to 3.6-V VCC operation. The SN74LVC126APWR features independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable (OE) input is low.
Parametrics
SN74LVC126APWR absolute maximum ratings: (1)VCC Supply voltage range: –0.5 to 6.5 V; (2)VI Input voltage range: –0.5 to 6.5 V; (3)VO Output voltage range: –0.5 to VCC + 0.5 V; (4)IIK Input clamp current: –50 mA; (5)IOK Output clamp current: –50 mA; (6)IO Continuous output current: ±50 mA; (7)Continuous current through VCC or GND: ±100 mA; (8)Tstg Storage temperature range: –65 to 150 ℃; (9)Ptot Power dissipation: 500 mW.
Features
SN74LVC126APWR features: (1)Operates From 1.65 V to 3.6 V; (2)Specified From –40℃ to 85℃ and From –40℃ to 125℃; (3)Inputs Accept Voltages to 5.5 V; (4)Max tpd of 4.7 ns at 3.3 V; (5)Typical VOLP (Output Ground Bounce) < 0.8 V at VCC = 3.3 V, TA = 25℃; (6)Typical VOHV (Output VOH Undershoot) > 2 V at VCC = 3.3 V, TA = 25℃; (7)Latch-Up Performance Exceeds 250 mA Per JESD 17; (8)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74LVC126APWR |
Texas Instruments |
Buffers & Line Drivers Tri-State Quad Bus |
Data Sheet |
|
|
||||||||||||
|
SN74LVC126APWRE4 |
Texas Instruments |
Buffers & Line Drivers Quad Bus Buffer Gate With 3-State Outputs |
Data Sheet |
|
|
||||||||||||
|
SN74LVC126APWRG4 |
Texas Instruments |
Buffers & Line Drivers Quad Bus Buffer Gate With 3-State Outputs |
Data Sheet |
|
|
||||||||||||
